* Used for high pressure applications.
* The Style RX is designed to fit the same groove design as a standard style R making joints interchangeable
*The Style RX has an increased height and utilizes the internal system pressure to energize and improve the seal as internal pressure » Suitable for flat bottom groove flanges
* Designs are also available for Sub sea applications.
1/2” to24” ： 150to 2500ASMEB16.20
26” to 36” ： 300 to 900 ASME B16.47 Series A 1
1-1/2” to 20” ： API 6A
TABLE B.2-DIMENSIONS OF IX SEAL RINGS ,
WITH PTFE COATING, ACC TO NORSOK-L005
Size/Pressure Class:
1 11/16” to 30” ： ” 2000 to 20000 API 6A
Two pressure passage holes in the SBX ring cross-section prevent pressure lock when connections are made up underwater. Two options are provided for drilling the pressure passage holes, a A plus tolerance of 0.2 mm (0.008 in) for width A and height H is permitted, provided the variation in width or height of any ring does not exceed 0.1 mm (0.004 in) along its entire circumference.
